DGD09CACA020100 - GEAR PUMP

#NSSP002400

Product Description

DGD09CACA020100 - GEAR PUMP

The DGD series direct drive gear pumps derive from the well-established mag drive MG200 series. Built to handle clean water and relatively viscous fluids at low pressure, the DGD series pump-motor unit has low pulsation and is capable of handling fluids at a maximum temperature of 70 °C (158 F). The extreme compactness of its design makes it the preferred choice where space is limited. Suction/discharge ports are 8 mm barbed end or with a 6 mm quick connector.

Motor version (brush type):

1500 rpm, 24 V DC
3400 rpm, 24 V DC
3900 rpm, 24 V DC

MAIN APPLICATIONS:

WATER PURIFICATION
LASER COOLING
SPRAYING
WATER RECIRCULATION
CONDENSATION REMOVAL
SYRUP DISPENSING
VENDING MACHINES
FOOD PROCESSING
DIGITAL MACRO PRINTING

MAIN FEATURES:

EASE FLOW OF VISCOUS FLUID
PRESSURE UPTO 4 BARS (58PSI)
FLOW RATES UPTO 160 I/h (42 GPH)
RPM : 1500
STAINLESS STEEL CASE
VECTRA GEARS
STRAIGHT TEETH DIRECT DRIVE
COMPACT DESIGN
NSF listed
Compact dimensions
Flow directly proportional to speed
12V & 24V DC options
NSF CERTIFIED PUMPS

Main Specifications:

DGD SERIES PUMP-MOTOR UNIT
TECHNOLOGY	External gear pumps
FLOW RATE (MIN)	40 l/h

FLOW RATE (MAX)	160 l/h
DIFFERENTIAL PRESSURE (MAX)	4 bar
STATIC PRESSURE (MAX)	6 bar
