HQC42001 Non-valved Hybrid Panel Mount Assembly, Dual 1/8
#NSSP005512
Product Description
HQC42001 Non-valved Hybrid Panel Mount Assembly, Dual 1/8"
Main Specifications:
- Material: Polypropylene
- Material Finish: Molded Grey
- Pressure Range: Vacuum to 45 psi, 3.1 bar
- Color: Gray
- Mounting Option: Panel Mount
- Temperature Range: 32°F - 120°F (0°C - 49°C)
- Seal Options: EPDM
- Valve Spring:316 Stainless Steel
- Valve Options: Valved
- Body Type: Other
- Bag Qty: 1
Main Features:
- Single connection point for pneumatic, fluid, data and power
connections between a device and its tool/hand piece
- Non-spill shutoff valves with dry-break technology
- Turnkey solution
- Off-the-shelf assembly
- Custom options available
Main Benefits:
- Increases safety and makes systems more user friendly
- Eliminate fluid drips upon disconnect and minimize air
inclusion
- Reduces multiple components
- Minimizes engineering design and manufacturing effort
- Flexibility to add additional fluid connector or elect
contacts.
Additional Information
| NESPL Code | NSSP005512 |
| Manufacturer Code | HQC42001 |
| Manufacturer | CPC Quick Connect & Disconnect Solutions |
| Type | Quick Fittings |
