20900 3/8 Hose Barb Valved Panel Mount Acetal Coupling Insert (PLCD42006 NSF)
#NSSP004273
Product Description
20900 3/8
Hose Barb Valved Panel Mount Acetal Coupling Insert (PLCD42006 NSF)
Main Features:
- Single
thumb latch
- Latch
always in position to accept insert
- Compact,
modular design
- Independent
quick connections
Main Benefits:
- Minimizes
inadvertent latch activation
- Ensures
leak-free operation
- Fits
well in the hand and is easy to wipe down
- Requires
minimal manual dexterity
Main Specifications:
- Material: Acetal
- Material Finish: Natural
- Pressure Range: Vacuum to 120 psi, 8.3 bar
- Color: White
- Mounting Option: Panel Mount
- Temperature Range: -40°F - 180°F (-40°C - 82°C)
- Seal Options: BUNA-N
- Valve Spring: 316 Stainless Steel
- Valve Options: Valved
- Body Type: Insert
- Bag Qty: 25
Additional Information
| NESPL Code | NSSP004273 |
| Manufacturer Code | 20900 |
| Manufacturer | CPC Quick Connect & Disconnect Solutions |
| Type | Quick Fittings |
